Description
FEATURES:
1. Compact, Light Weight, Sleek unit
2. Wall Mountable as well as Table-top unit
3. Standard input Gas connections
4. Built-in Rechargeable battery, charger and switch over circuit
5. Big Touch screen color LCD display control panel
6. All six pressures’ Real time continuous display
7. All six pressures’ user adjustable High & Low Alarm setting – Audio and Video alarms
8. Real Date-Time display with Room Temperature and Humidity measurement.
9. Wi-Fi Enabled Control panel for Mobile connectivity for wireless monitoring + Alarm + Control +
Data storage + Data Analysis + Report Generation
SPECIFICATIONS:
1. Five Positive Pressure channels: 0-100 PSI with 1% Accuracy, 1 PSI Resolution
2. Vacuum channel: 0-500 mm Hg with 1% accuracy, 1 mm Hg resolution
3. Room Temperature: 0-50 degree C with 1 degree C resolution
4. Room Humidity: 0-100% with 1% resolution
5. Battery backup time after full charge: 4-6 hours
6. Wide Input voltage range: 90 v to 260 v to cover mains voltage fluctuations
7. Dimensions: 280 mm X 125 mm X 110 mm, Weight: 0.5 Kg
